Part No: GW3648D-ES Storage Systems – Hybrid Inverter
GoodWe ES series Full Hybrid inverter is best suited to grid-connected PV systems: enhancing self-consumption and providing 3.6kW backup power to essential loads in the event of loss of grid. It can intelligently control the flow of energy.
Note: Goodwe are changing cables from Amphenol to MC4. Please note there may be a change of cables in your order; this will have no impact on the overall product solution.
Both MPPT charge controller and inverter are fully integrated
Intelligent battery management function
Capable of being grid-interactive or grid-independent
Compatible with various Lead-acid and Li-Ion battery types.
IP65 dust-proof and water-proof rating
45°C full-load output
Monitoring of inverters is free via computers or mobile phones and extremely easy to use
Fanless, low-noise design
Supplier Part No:
GW3648D-ES
Weight:
36 kg
Rated Power:
3,600 W
Min PPT Voltage:
125 V
Max PPT Voltage:
550 V
DC Startup Voltage:
150 V
DC Shutdown Voltage:
125 V
Max Input Voltage:
580 V
Max DC Power:
4,600 W
Max AC Power:
3,600 W
Surge AC Power (15 Seconds):
5,520 W
Max DC Current:
22 A
Max DC Inputs:
2
Has DC Fuses:
0
Connector:
MC4
Included Connectors:
2
Euro Efficiency:
97 %
Transformer:
None
IP Rating:
IP65
MPPT Quantity :
2
Has Integrated DC Switch:
Yes
Warranty:
5 years
